RECTANGLE TWIN Series
IP69K and IK10 Shock Rated
NEED UPDATES!!!
The Tuff-Tube is perfect for harsh conditions in polluted environments where a high level of quality lighting is needed. Rated IP69K with an IK10 shock rating, the Tuff-Tube handles water, dust, humidity, corrosion, vibration, and sudden impact with ease. Constructed of a high-quality PC/PE tubular housing and stainless steel caps, this fixture can be used indoors or outdoors and installs easily with little maintenance over the lifetime of the fixture. The Tuff-Tube is perfect for agricultural and livestock applications, food processing plants, refrigeration specification, and car washes.
Ratings and Certifications
UL 1598 Wet Location
UL 8750 LED Safety
CSA C22.2 No. 250.13-14
IP69K
IK10
| Electrical | |
| Power (W) | 20W, 36W, 45W |
| Voltage(s)/Frequency | AC120 – 277V @50/60HZ |
| Power Factor | ≥95%@120V |
| THD | <10% |
| L70 | >75,000 Hours |
| Surge Protection | 4KvA |
| Optical | |
| Lumen Output | 2,700Lm, 4,860Lm, 6,075Lm |
| Lumen Efficacy | 135Lm/W |
| Beam Angle(s) | 120° |
| CRI | Ra>80 |
| Mechanical | |
| Ambient Operating Temperature | -4°F to 104°F (-20°C – 40°C) |
| IP / IK Rating | IP69K / IK08 (PE) IK10 (PC) |
| Construction | Aluminum Board, Polymer Tube Housing, Stainless Steel End-caps |
| Hardware | Marine Grade Stainless Steel |
| Lens Material | Polycarbonate or Polyethylene |
| Mounting Options | Stainless Steel Snap Rings |
| Weight | See Downloadable Specification Sheet |
| Dimensions (L×W×H) | See Downloadable Specification Sheet |
| Connections | M20x1.5 SS316 Cable Gland |
| Warranty/Certifications | |
| Warranty Terms | 5 Years fixture warranty |
